PTFE는 Polytetrafluoroethylene의 약자이며 대표적인 불소수지로 폴리에틸렌의 분자구조에서 수소원자를 불소원자로 치환시킨 고분자물질로서 내마모성, 내수성, 내유성, 내화학성,
내약품성, 저마찰계수, 비점착성, 전기절연성, 불연성, 내후성등을 보유하고 무독성 물질로 알려져 있습니다. 특히 -250℃ ~ 300℃ 정도의 광범위한 사용온도에서
안정성을 유지하여 특성이 변화하지 않으며 압출, 사출, 도료, 접착, 잉크, 코팅, 페인트, 파이프, 배관, 전자재료 및 다양한 산업에서 핵심 원료 및 첨가제로 사용되고 있습니다.
FEATURES
- Excellent chemical inertness
- Outstanding resistance to chemical corrosion : strong acid, alkali, oxidant, etc.
- Broad range of temperature from -200℃~250℃
- Superior electric insulation, which is not affected by temperature and frequency.
- Non-stick to all other materials.
- No-Absorption of Moisture
- Flame retardation.
APPLICATIONS
- Non Stick Coating, Spray Coating, Roller Coating, Silk-Screen Coating
- Additives for Paint, Ink, Printing
- Additives for Rubber, Silicone, Urethan, EPDM, NBR, TPU, Elastomer
- Additives for Off Set Ink, UV Ink, Can Ink, Photo Ink, Metal Ink, Resist Ink
- Additives for POM, PPS, LCP, PEEK, PC, PA, PES, PI, PEI, PAI, PSU, PEN, PBT, ABS, PP, PE, Epoxy, Phenol Resins
PACKING & HANDLING
- Stored under frost proof environment under optimum 3-30℃ temperature
- Should not store under 0℃ or over 40℃ temperature
- Homogenized by gentle rolling or stirring when storing or using
- Adjust viscosity by adding distilled water or anion surfactant
- PH could be adjust by ammonium hydroxide
- Package in 25L PE drum with 25kg(55lb) and 1000L IBC drum with 1250kg(2750lb)
PRODUCT & SPECIFICATIONS
| Product |
Application |
Type |
Size(um) |
Tensile(Mpa) |
Elongation(%) |
Melting(℃) |
| M40 |
Molding |
Powder |
20~40 |
35 |
375 |
327 ± 10 |
| M120 |
Molding |
Powder |
120~180 |
35 |
375 |
327 ± 10 |
| G401 |
Gasket/Seal/Rod |
Powder |
490 |
35 |
330 |
327 ± 10 |
| Product |
Application |
Type |
Size(um) |
EXT(Mpa) |
T.I |
Melting(℃) |
| F100 |
Sealing Tape |
Powder |
500 |
8 |
< 50 |
341 |
| F500 |
Tube/Cable/Wrap |
Powder |
480 |
23 |
< 7 |
341 |
| F1000 |
Wire/Tube/Cable |
Powder |
480 |
53 |
< 50 |
341 |
| Product |
Application |
Type |
S.C(% PTFE) |
Size(um) |
PH 23(℃) |
Visco (mPa.s) |
| D60 |
Non Stick Coating |
Dispersion |
60 |
0.25 |
9 |
20 |
| Product |
Application |
Type |
Gravity(g/L) |
Size(um) |
M.P(℃) |
S.A(cm2//g) |
| MV1 |
Lubricant |
Micropowder |
350 |
1~3 |
>326 |
17 |
| MV3C |
Paint/Coating |
Micropowder |
350 |
3~5 |
>326 |
17 |
| MV3I |
Ink/Print |
Micropowder |
350 |
3~5 |
>250 |
17 |
| MV3E |
Rubber/EPDM/SBR |
Micropowder |
350 |
5 |
>326 |
17 |
| MV5P |
PA/POM/PC |
Micropowder |
350 |
9~12 |
>326 |
17 |
APPLICATIONS
FㆍD Series
- Sealing material tape
- Tube/Cable/Wrap
- Wire/Tube/Cable
- Non-stick coating
MV Series
- Lubricant
- Paint/Coating
- Ink/Print
- Rubber/EPDM/SBR
- PA/POM/PC
